MS-M854H 395-415W

Name: MS-M854H 395-415W
Brand: Maysun Solar
SKU: 56924
Price: 0.20800 USD
Availability: InStock

Maysun Solar Co., Ltd

Prezzo:

A partire da €0,194 / Wp

Tipo:	Monocristallino
Fascia di Potenza:	395 ~ 415 Wp
Regione:	Cina

Note: La tua Richiesta verrà inviata direttamente a Maysun Solar Co., Ltd.

Descrizione:

A sleek and modern all-black frame packed with advanced technologies

Power range from 395 to 415 watts and an efficiency of up to 21.26%

Advanced half-cut technology and a multi-busbar design

Series-parallel wiring reduces shading loss

Excellent temperature performance

Informazioni del Prodotto
Profilo Della Compagnia

Caratteristiche del Prodotto

Numero Modello

MS-M854H 395W

MS-M854H 400W

MS-M854H 405W

MS-M854H 410W

MS-M854H 415W

Garanzia

Garanzia Prodotto

12 Anni

Garanzia potenza

12 anni di 90% Potere Output, 25 anni di 85% Potere Output

Dati Elettrici in Condizioni Standard

Potenza Massima(Pmax)

395 Wp

400 Wp

405 Wp

410 Wp

415 Wp

Tensione alla Massima Potenza (Vmpp)

31,25 V

31,36 V

31,47 V

31,59 V

31,71 V

Corrente alla massima potenza (Impp)

12,64 A

12,76 A

12,87 A

12,98 A

13,09 A

Tensione a Vuoto(Voc)

37,02 V

37,11 V

37,2 V

37,29 V

37,38 V

Corrente di corto circuito (Isc)

13,51 A

13,63 A

13,74 A

13,85 A

13,96 A

Efficienza del modulo

20,23 %

20,48 %

20,74 %

21 %

21,26 %

Tolleranza sulla Potenza (+)

+ 3 %

Tolleranza sulla Potenza (-)

- 3 %

Condizioni di prova standard (STC): massa d'aria AM 1,5, irraggiamento 1000W/m2, temperatura della cella 25 ° C

Dati elettrici con NOCT

Potenza Massima(Pmax)

292 Wp

295 Wp

299 Wp

305 Wp

309 Wp

Tensione alla Massima Potenza (Vmpp)

28,43 V

28,53 V

28,64 V

28,81 V

28,92 V

Corrente alla massima potenza (Impp)

10,26 A

10,35 A

10,43 A

10,59 A

10,68 A

Tensione a Vuoto(Voc)

34,2 V

34,27 V

34,35 V

34,67 V

34,76 V

Corrente di corto circuito (Isc)

10,91 A

11 A

11,1 A

11,19 A

11,27 A

Temperatura

45±2 °C

Temperatura di esercizio nominale della cella (NOCT): 800W/m2, AM 1,5, velocità del vento 1m / s, temperatura ambiente 20 ° C

Valutazioni di Temperatura

Temperatura Operativa

40~+85 °C

Coefficiente di Temperatura di Pmax

0,36 %/°C

Coefficiente di Temperatura di Voc

0,29 %/°C

Coefficiente di Temperatura di Isc

+0,048 %/°C

Valutazioni Massime

Tensione Massima di Sistema

1500 V

Tensione Nominale del Fusibile

25 A

Dati Matrial

Dimesioni (A/L/P)

1722x1134x30 mm

Peso

21,5 kg

Tipo Cella

Monocristallino

Dimensione Cella

182x182 mm

Numero Cella

108

Tipo Vetro

Rivestimento Anti-Riflesso, Temperato

Spessore del Vetro

3,2 mm

Tipo di incapsulamento

EVA

Tipo Back Cover

TPT

Tipo di Telaio

Lega di Alluminio Anodizzato

Diodi Scatola di Derivazione

Protezione Scatola di Derivazione

IP 68

Tipo di Connettori

MC4

Diametro Cavi

4 mm²

Lunghezza del Cavi

300 mm

PDF

Scarica Il PDF Del Produttore

MS-M854H 395-415W

1722 * 1134 * 30mm;

108 cells, Module efficiency: 21.26%, Mono 10BB Half-cut Module;

TUV, CE, CB, ISO9001, CQC certified;

12 years product warranty;

25 years linear power output warranty;

Package: 36 Pcs/Pallet, 936 pcs/40' Hq;

Half-Cut technique leads to increased power output. When the cells are cut into halves, the current are also halved, which enables less internal loss;

Series-parallel wiring mode results in reduced shading loss;

The temperature of HC module is 1.6 °C lower than that of the conventional module under the same working condition, which results to less power loss.

About the Company

Maysun Solar Co., Ltd. is a high-tech enterprise specializing in the production of solar cell modules. At present, it has developed into a comprehensive energy management company integrating R & D and production of photovoltaic module products, development, installation and maintenance of solar power station, striving to create high-quality products and services for clean and renewable energy.

Since its establishment, in order to expand production capacity and improve production technology, the company has introduced first-class modern production equipment, improved the conversion efficiency and quality of products, and reduced production costs. Continuously committed to the development of new technology, it has successfully applied for more than 10 invention patents, with products passing ISO9001, TUV, CQC, CE certifications.

Maysun Solar has two main brands: “Maysun Solar” mainly promotes overseas markets. Its products are exported to Germany, Italy, France, Spain, Belgium, Portugal, Netherlands, Pakistan and other counties, and are widely praised by customers. At the same time, in order to actively respond to the national call of "carbon peak, carbon neutral”, Maysun Solar launched the high-end component brand “Rachida”, which mainly serves the distributed power station and centralized ground power station pursuing high power generation and high cost performance. Maysun Solar will do its best to protect the green earth, so that more families can always enjoy renewable solar energy and build a clean living environment. Maysun Solar is also committed to becoming a leading photovoltaic manufacturer in the industry and making its own contribution to global energy conservation and environmental protection.
