TSM144-9-535M-555M

Zhejiang Twinsel Electronic Technology Co., Ltd.

Tipo:	PERC
Fascia di Potenza:	535 ~ 555 Wp
Regione:	Cina

Note: La tua Richiesta verrà inviata direttamente a Zhejiang Twinsel Electronic Technology Co., Ltd..

Descrizione:

Comprehensive product and system certifications including IEC 61215, ISO 9001:2015, etc
Excellent low irradiance performance
Excellent PID resistance
Module Imp binning radically reduces string mismatch losses

Informazioni del Prodotto
Profilo Della Compagnia

Caratteristiche del Prodotto

Numero Modello

TSM144-9-535M

TSM144-9-540M

TSM144-9-545M

TSM144-9-550M

TSM144-9-555M

Garanzia

Garanzia Prodotto

12 Anni

Garanzia potenza

12 anni di 90% Potere Output, 25 anni di 80% Potere Output

Dati Elettrici in Condizioni Standard

Potenza Massima(Pmax)

535 Wp

540 Wp

545 Wp

550 Wp

555 Wp

Tensione alla Massima Potenza (Vmpp)

41,87 V

41,99 V

42,11 V

42,2 V

42,29 V

Corrente alla massima potenza (Impp)

12,79 A

12,87 A

12,96 A

13,04 A

13,13 A

Tensione a Vuoto(Voc)

49,5 V

49,6 V

49,7 V

49,8 V

49,91 V

Corrente di corto circuito (Isc)

13,64 A

13,74 A

13,84 A

13,94 A

14,04 A

Efficienza del modulo

20,7 %

20,9 %

21,1 %

21,3 %

21,5 %

Condizioni di prova standard (STC): massa d'aria AM 1,5, irraggiamento 1000W/m2, temperatura della cella 25 ° C

Dati elettrici con NOCT

Potenza Massima(Pmax)

398,5 Wp

402 Wp

405,8 Wp

409,4 Wp

413,3 Wp

Tensione alla Massima Potenza (Vmpp)

38,7 V

38,8 V

38,9 V

39 V

39,1 V

Corrente alla massima potenza (Impp)

10,3 A

10,36 A

10,43 A

10,5 A

10,57 A

Tensione a Vuoto(Voc)

46,68 V

46,77 V

46,87 V

46,96 V

47,07 V

Corrente di corto circuito (Isc)

11,18 A

11,27 A

11,35 A

11,43 A

11,51 A

Temperatura

44±2 °C

Temperatura di esercizio nominale della cella (NOCT): 800W/m2, AM 1,5, velocità del vento 1m / s, temperatura ambiente 20 ° C

Valutazioni di Temperatura

Temperatura Operativa

40~85 °C

Coefficiente di Temperatura di Pmax

0,35 %/°C

Coefficiente di Temperatura di Voc

0,275 %/°C

Coefficiente di Temperatura di Isc

0,045 %/°C

Valutazioni Massime

Tensione Massima di Sistema

1500 V

Tensione Nominale del Fusibile

25 A

Dati Matrial

Dimesioni (A/L/P)

2279x1134x35 mm

Peso

27,8 kg

Tipo Cella

PERC

Numero Cella

144

Tipo Vetro

Rivestimento Anti-Riflesso, Temperato

Tipo di Telaio

Lega di Alluminio Anodizzato

Protezione Scatola di Derivazione

IP 68

Diametro Cavi

4 mm²

Lunghezza del Cavi

350 mm
