Rosefinch L

Garnde Solar Energy Corp.
Prezzo:
MSRP da €400 / Unità
Tecnologia: MPPT
Garanzia Prodotto: 2 Anni
Regione: Cina Cina
Note: La tua Richiesta verrà inviata direttamente a Garnde Solar Energy Corp..

Descrizione:

• Auto identification and selection of system voltage
• High performance 32 bits CPU
• Wide PV input voltage range, convenient for system configuration
• MPPT charge mode, increase power usage efficiency of solar panels
• LCD display, intelligent batteries charging status display
• Running status display of solar panels, batteries and loads
• Optional RS485 communication port, convenient for user integration management
• Over-charge protection, over-discharge protection, over-load protection, short-circuit protection and battery wrong-connecting protection, anti-thunder-stroke protection

Caratteristiche del Prodotto

Numero Modello
RF96-50 RF96-100
Specificazione
Potenza
5600 W 11200 W
Prezzo (MSRP)
€400 / Unità €576 / Unità
Dati Elettrici
Potenza Fotovoltaica Massima in Entrata
5600 W 11200 W
Tensione Max. Circuito Aperto Pannello Solare
300 V 300 V
Tensione Nominale del Sistema (Batteria)
96 V 96 V
Corrente Massima di Carica Batteria
50 A 100 A
Efficienza di Picco della Conversione
99,00 % 99,00 %
Informazioni Generali
Dimensioni (A/L/P)
315x250x108 mm 310x250x108 mm
Peso
4,50 Kg 5,60 Kg
Tipo Batteria GEL, AGM, VLA, Ni-Cd, Li-poly, Li-ion, NiMH, Piombo Carbonio
Classe di Protezione IP 20
Temperatura Operativa -15 ~ +50 °C
Range di Temperatura di Immagazzinamento -20 ~ +60 °C
Porte di Comunicazione RS 485
Display LCD
Lingua Inglese
Sensore di Temperatura
Modalità di Raffreddamento Ventilatore
Caratteristiche di Protezione
Caratteristiche di Protezione Protezione al Corto Circuito, Protezione Inversione Polarità FV, Protezione Sovratensione FV, Protezione Notturna Corrente Inversa FV, Protezione Inversione Polarità Batteria, Protezione Sovraccarico, Protezione Sovraccarica, Protezione Sovrascarica, Protezione Sovratemperatura
PDF
Scarica Il PDF Del Produttore

Garnde Solar Energy Corp.


Garnde Solar Energy Corporation is a Solar Charge Controller, Solar Inverter manufacturer and Solar Energy Solution, Solar System provider, exporter in China.
Garnde offer high quality Solar Charge Controllers, Solar Inverters and complete Off-Grid Solar System, Energy Storage Solar System, Grid-connected Solar System, UPS for customer to build Green Energy Supply in his market. Moreover, Garnde provides free consultation and do customized solar system when needed.
During the past years, Garnde were involved into the LED technology and Solar Power technology with mission of bringing green energy to people. We have supplied/built sizable solar components/solar systems all over the world including Centro America, South America, South-East Asia, South Asia, Africa and Europe.

Vision
To be one of the leading suppliers in solar energy field, help more and more people to use solar energy with lowest cost by latest technology.

Mission
To design and supply innovative solar energy devices and solutions by nurturing in-house manufacturing and engineering talent and collaboration with valued partners. Contribute to facilitate the live of people on earth by using solar energy with firmly believe that solar and energy storage is the future ultimate energy solution of human beings.


Values

To our customer: Customer first. Create value for our customer is the only reason that we can live and grow.
To our employee: Be diligent, be warm-hearted, to be company co-partner and become destiny community with the company, to achieve an ideal high level of self realization



Product Introduction

Rosefinch series solar charge controllers are developed for off-grid solar system and battery backup solar system. Maximum Power Point Tracking (MPPT) charging technology can increase 20-30% power usage efficiency of solar panels more than PWM charging technology. Efficiency up to 99% MPPT charging, the adventurer increases battery lifespan by regulating the charge flowing from the solar panels to the battery bank.

• Auto identification and selection of system voltage
• High performance 32 bits CPU
• Wide PV input voltage range, convenient for system configuration
• MPPT charge mode, increase power usage efficiency of solar panels
• LCD display, intelligent batteries charging status display
• Running status display of solar panels, batteries and loads
• Optional RS485 communication port, convenient for user integration management
• Over-charge protection, over-discharge protection, over-load protection, short-circuit protection and battery wrong-connecting protection, anti-thunder-stroke protection



 CONNECTION DIAGRAM
